Candle is a free, basic CNC machine control software that can be used to control the Minimillr for 2D and 3D geometry. It is uncomplicated and perfect for beginners. It incorporates a G-code visualizer and has the essential functions needed to run G-Code programs. Candle works with CNC machines controlled by GRBL firmware. To create a G-code image for GrblControl Candle, you can use software like bCNC or Universal Gcode Sender (UGS).
| Characteristics | Values |
|---|---|
| Software | Candle GRBL software is free to use, basic CNC machine control software. |
| Compatibility | Windows 8 or later. |
| Installation | Disconnect any offline controllers. |
| Connection | Set the COM port as per the one in Control Panel. Usually, this will not be COM1. Set baud to 115200 (default setting). |
| Functionality | Incorporates a G-code visualizer and essential functions for running G-Code programs. |
| Machine Control | Candle is recommended for controlling the Minimillr. |
| Alternative Software | Universal GCode Sender, Easel, bCNC. |
Explore related products
What You'll Learn
Ensure your offline controller is disconnected from your CNC
Ensuring that your offline controller is disconnected from your CNC is a crucial step when setting up or troubleshooting your CNC machine. This step is often mentioned in user guides and forums for CNC machines, and it can be an important part of resolving issues with your CNC controller.
When working with a CNC machine, it is essential to follow safety protocols and guidelines. One critical safety feature in CNC systems is voltage isolation, which separates the working voltage from the control voltage. This isolation protects both the controller and the CNC machine from electrical issues and interference, thereby preventing electrical damage and ensuring the reliability of the controller.
Before connecting or disconnecting any components, it is recommended to turn off the power to the controller and the CNC machine. This precaution helps prevent any unexpected behavior or electrical interference during the process. By powering off the devices, you reduce the risk of electrical damage and ensure a safer working environment.
To physically disconnect your offline controller from the CNC, start by locating the USB cable that connects the two devices. Carefully unplug the USB cable from both the controller and the CNC router. This step ensures that the offline controller is completely disconnected from the CNC machine, allowing for safe adjustments or replacements.
It is important to note that different CNC machines may have unique requirements or procedures for disconnecting the offline controller. Always refer to the user manual or seek guidance from the manufacturer's website or support channels if you are unsure about the specific steps required for your CNC machine.
