An isofootcandle diagram or plot is a tool used to evaluate and compare different luminaires for a given application. It graphically represents a particular luminaire's lighting pattern, in illuminance, as the light strikes a horizontal surface. The diagram provides information on the distribution of light in a plan, showing the angle of emitted light and its intensity. The mounting height of the floodlight determines the dimensions of the diagram, with grid lines indicating the distance from the aiming point. The isofootcandle plot is useful for determining how much area a light fixture can cover and is often provided by manufacturers for architects and engineers to select and specify appropriate lighting products.
| Characteristics | Values |
|---|---|
| Definition | A plot that graphically represents a particular luminaire's lighting pattern, in illuminance, as the light strikes a horizontal surface. |
| Use | A common tool for evaluating and comparing different luminaires for a given application. |
| Users | Architects and engineers use these plots to select and specify appropriate lighting products. |
| Data | Includes foot-candle calculations shown with the luminaire at various mounting heights. |
| Grid lines | Represent the distance to either side of the floodlight. |
| Grid values | Show the distance in line with the aiming direction of the floodlight. |
| Contours | Represent the luminaire's applied performance. |
| Light distribution | Straight lines radiating from the centre point identify the angle of light emitted, while circles represent intensity. |
Explore related products
![The Candlestick Trading Bible: [3 in 1] The Ultimate Guide to Mastering Candlestick Techniques, Chart Analysis, and Trader Psychology for Market Success](https://m.media-amazon.com/images/I/61eKxh-x7FL._AC_UY218_.jpg)
What You'll Learn
- ISO foot-candle plots graphically represent a luminaire's lighting pattern
- Plots are based on mounting height and aim point
- Foot-candle calculations are shown at various mounting heights
- Plots are used to evaluate and compare different luminaires
- Straight lines radiating from the centre point show the angle of emitted light
ISO foot-candle plots graphically represent a luminaire's lighting pattern
ISO foot-candle plots are a common tool for evaluating and comparing different luminaires for specific applications. They are often provided by luminaire manufacturers for architects and engineers to use when selecting appropriate lighting products.
The dimensions for the diagram are based on the mounting height (MH) of the floodlight. The aiming point (p) is also based on the mounting height. The grid line values left and right give the distance to either side of the floodlight. The values up the side show the distance in line with the aiming direction of the floodlight. Each isofootcandle line shows where the footcandle level is the same.
As early as the schematic design phase of a project, isofootcandle plots can be used for rough luminaire layouts for site lighting. For example, to estimate a fixture layout, you can start from the perimeter, where the isofootcandle trace crosses the reference line, to establish the maximum single fixture distance to the site perimeter.
